Vacuum Chamber Description

A vacuum chamber is a hard enclosure from which all the gases and air are discharge thanks to a vacuum pump.

Vacuum chambers are required to avoid contamination of samples in many disparate kinds of spectroscopy and for thin film depositions. Most vacuum chambers are fabricated in aluminum because it is nonmagnetic and so it allow to controll magnetic fields from outside the chamber.
Aluminum is a good choice also because compared to other types of metals, it absorbs minor water and trace gases.

UHV (Ultra high vacuum) means having pressures lower than about 10-13 atmosphere.
Vacuum chambers can be really useful: even at 10-10 atmosphere, it takes only 1 second to cover a surface with a contaminant.

For more info about it click here and read the wikipedia complete description.

Posted in Vacuum Chambers Info | Tagged , , | Leave a comment

What Materials Are Vacuum Chambers Made Of

Although there are several options available in the production of vacuum chambers, there are just a few materials that seem to be used over and over again. There are several reasons why these materials work the best and we’ll explore those reasons right now.

vacuum chamberFor high vacuum chambers, the material most commonly used is a high grade 300-series stainless steel. This metal has some great properties that make it perfect for use in a vacuum. First and foremost, the steel is mechanically strong. It is able to withstand incredible forces and very low pressures when it is used correctly. Another great property of the metal is that is weldable. Many models of vacuum chambers are sealed not only by o-rings, but by welded metal.

Another desirable property of 300-series stainless steel is that it has a magnetic permeability that is very close to 1. Which means that it will almost never interfere with any magnetic fields. Besides that, the metal has a very high resistance to atmospheric corrosion, which goes a long way when you’re worried about durability.


Sometimes, when researchers will be operating in the HV Torr range, perhaps for a large simulation chamber, they may choose to produce the chamber using a mild steel. This is most often done because it is a cost effective option when compared to 300-series steel such as 316L. However, there are several problems associated with mild steel. The first being that it does not have the desirable magnetic permeability of stainless steel. Besides that it does not carry the corrosion resistance or out-gassing properties.

If the researchers desire to control a magnetic force inside of the vacuum from outside of the chamber, different kinds of aluminum may be a good option.

If you are concerned with preventing external fields from entering a vacuum chamber, mu-metal is a good material.

Posted in Vacuum Chambers Info | Tagged , , , | Leave a comment

Eisco Magnetic Field Chamber Model

Eisco Magnetic Field Chamber Model

Eisco Magnetic Field Chamber Model Rating:
List Price: unavailable
Sale Price: $118.25
Availability: unspecified

Product Description

Model, Magnetic field chamber; Eisco; Acrylic chamber (98 x 163 x 98mm); Iron fillings suspended in silicon oil; Magnets insert into internal tunnel (163 x 25mm); Other magnets can be positioned at side of chamber

Details

No features available.

Posted in Special Offerts | Leave a comment

Glove Bag Inflatable Glove Chamber, 11.5″ Equipment Sleeve, 6/pk

Glove Bag Inflatable Glove Chamber, 11.5" Equipment Sleeve, 6/pk

Glove Bag Inflatable Glove Chamber, 11.5" Equipment Sleeve, 6/pk Rating:
List Price: unavailable
Sale Price: $174.00
Availability: unspecified

Product Description

An alternative to standard glove boxes-these durable, polyethylene glove chambers are reusable, yet priced to be disposable. Chambers are easy to use-just slide your equipment through the sleeve(s), seal, connect the gas port (accepts 3/8'' ID tubing) to your gas supply, and inflate. Models 04408-30, -32, -34, -36, and -38 have a single equipment sleeve and a gas port at the rear of the bag. Model 04408-40 has two equipment sleeves and two rear-mounted gas ports for added versatility.

Details

  • Glove Bag Inflatable Glove Chambers
  • Protect yourself and your materials quickly without giving up lab space
  • Effectively eliminate oxygen and moisture during material manipulation operations
  • Establish high-purity working atmosphere-in minutes
  • Disposable chambers simplify cleanup
  • Chamber size: 17 in L x 17 in W x 11 in H
  • Type: Glove Chambers
  • Manufacturer number: 108DX-17-17H
  • Model: 108DX-17-17H
  • Part Number: AO-04408-30
  • Package Quantity: BOX

Posted in Special Offerts | Leave a comment

Salvis Vacucenter Vacuum Oven, 1.8 cu ft, 115 VAC

Salvis Vacucenter Vacuum Oven, 1.8 cu ft, 115 VAC

Salvis Vacucenter Vacuum Oven, 1.8 cu ft, 115 VAC Rating:
List Price: unavailable
Sale Price: $9,750.00
Availability: unspecified

Product Description

Overtemperature control shuts off heating when temperature reaches 10°C above set point or when oven door is open. Full-view glass window lets you safely view samples during operation. Rounded interior corners make cleanup simple. Microprocessor controller features an alphanumeric digital display with easy-to-operate keypad, menu prompts in five selectable languages, ability to store 50 programs with 15 steps, real-time clock, timer, and RS-232 output. The 4-mm hose barb purge port connects to a needle valve that gently regulates gas or air into the oven without disturbing samples. An electromagnetic valve operates the vacuum connection (6-mm hose barb) at the back of the oven. In case of power failure, this valve closes automatically to protect your samples.

Details

  • Salvis Vacucenter Ovens
  • Microprocessor-controlled temperature regulation and jacket heating system provide excellent precisi
  • Spring-loaded metal safety catch opens oven door slightly to prevent overpressure conditions
  • Double-paned glass door and high-quality insulation keep heat in and the surface cool
  • Insulated silicone door seal that prevents the escape of harmful fumes
  • Capacity (Liters): 51.1
  • Maximum temperature (° C): 200
  • Maximum temperature (° F): 392
  • Capacity (cu ft): 1.8
  • Temp range: 10°C above ambient to 200°C
  • Vacuum range: 1 bar to 0.60 mbar
  • Vacuum display: dial gauge
  • Rise time: 65 min to 200°C
  • Resolution: 0.1°C
  • Amps: 11.8
  • Display: alphanumeric LCD
  • Control type: microprocessor
  • No. of shelf positions: 5
  • No. of shelves: 1
  • Power (VAC): 115
  • Power (Hz): 60
  • Power (Amps): 11.8
  • Power (watts): 5500
  • Construction: 316 stainless steel interior and powder-coated steel exterior
  • Chamber size: 13-¾"W x 13-¾"H x 16-½"D
  • Uniformity: ±1.7 at 100°C
  • Dimensions: 25-3/8"W x 18-½"H x 20-11/16"D
  • Power: 115 VAC, 60 Hz
  • Timer: 0 to 999 hours 99 minutes
  • Manufacturer number: 31A04121

Posted in Vacuum Ovens | Tagged , , , , | Leave a comment

PID-controlled vacuum drying oven, 0.35 cu ft, 120 VAC

PID-controlled vacuum drying oven, 0.35 cu ft, 120 VAC

PID-controlled vacuum drying oven, 0.35 cu ft, 120 VAC Rating:
List Price: unavailable
Sale Price: $2,815.00
Availability: unspecified

Product Description

These microprocessor-based ovens are accurate and reliable. Large, flat heater embedded behind the chamber wall provides excellent temperature uniformity and quick heating times. A self-diagnostic function visually alerts you and turns off the circuit heater if the temperature sensor, triac, or heater malfunctions. Ovens are well built and virtually maintenance-free. Silicone door gasket and positive door latch ensure a tight seal. Vacuum and purge valves are located on top of oven for easy access; connections accept 3/8" ID tubing.

Details

  • Yamato Benchtop Vacuum Drying Ovens
  • PID-Controlled vacuum drying ovens with vacuum and purge valves located on top of oven for easy acce
  • Reversible door opens from the left or the right
  • Interior constructed of type 304, stainless steel with cold rolled steel exterior and melamine resin
  • Rock wool heating insulation
  • Decompressed chamber direct heating method
  • Heater Mica heater, 0.68kW (Model 33950-10 features a Mica heater, 1.05kW)
  • Vacuum gauge Bourdon tube type, 101 to 0kPa (Gauge pressure)
  • Tempered glass observation window (12 mm thickness) and polycarbonate resin plate
  • PlD temperature control by microprocessor
  • Digital temperature setting method with up/down key
  • Electric leakage breaker safety countermeasures
  • Temperature control accuracy ±1.5degC (at 150degC)
  • Time to maximum temperature approx. 70 minutes (model 33950-10 approximately 100 min.)
  • Maximum temperature: 240°C
  • Capacity (Liters): 9.9
  • Maximum temperature (° C): 240
  • Maximum temperature (° F): 464
  • Capacity (cu ft): 0.35
  • Temp range: 40 to 240°C
  • Vacuum range: 101 to 0.1 kPa (at absolute pressure), 760 to 1 mm Hg
  • Vacuum display: Bourdon tube type, 101 to 0kPa (Gauge pressure)
  • Resolution: 0.1C
  • Display: 4-digit LED
  • Temp control accuracy: ±1.5°C (at 150°C)
  • Control type: microprocessor PID
  • No. of shelf positions: 2
  • No. of shelves: 2 (stainless steel)
  • Power (VAC): 115
  • Power (Hz): 50/60

Posted in Vacuum Ovens | Tagged , , , , | Leave a comment

PID-controlled vacuum drying oven, 1.0 cu ft, 120 VAC

PID-controlled vacuum drying oven, 1.0 cu ft, 120 VAC

PID-controlled vacuum drying oven, 1.0 cu ft, 120 VAC Rating:
List Price: unavailable
Sale Price: $3,829.00
Availability: unspecified

Product Description

These microprocessor-based ovens are accurate and reliable. Large, flat heater embedded behind the chamber wall provides excellent temperature uniformity and quick heating times. A self-diagnostic function visually alerts you and turns off the circuit heater if the temperature sensor, triac, or heater malfunctions. Ovens are well built and virtually maintenance-free. Silicone door gasket and positive door latch ensure a tight seal. Vacuum and purge valves are located on top of oven for easy access; connections accept 3/8" ID tubing.

Details

  • Yamato Benchtop Vacuum Drying Ovens
  • PID-Controlled vacuum drying ovens with vacuum and purge valves located on top of oven for easy acce
  • Reversible door opens from the left or the right
  • Interior constructed of type 304, stainless steel with cold rolled steel exterior and melamine resin
  • Rock wool heating insulation
  • Decompressed chamber direct heating method
  • Heater Mica heater, 0.68kW (Model 33950-10 features a Mica heater, 1.05kW)
  • Vacuum gauge Bourdon tube type, 101 to 0kPa (Gauge pressure)
  • Tempered glass observation window (12 mm thickness) and polycarbonate resin plate
  • PlD temperature control by microprocessor
  • Digital temperature setting method with up/down key
  • Electric leakage breaker safety countermeasures
  • Temperature control accuracy ±1.5degC (at 150degC)
  • Time to maximum temperature approx. 70 minutes (model 33950-10 approximately 100 min.)
  • Maximum temperature: 240°C
  • Capacity (Liters): 26.6
  • Maximum temperature (° C): 240
  • Maximum temperature (° F): 464
  • Capacity (cu ft): 1
  • Temp range: 40 to 240°C
  • Vacuum range: 101 to 0.1 kPa (at absolute pressure), 760 to 1 mm Hg
  • Vacuum display: Bourdon tube type, 101 to 0kPa (Gauge pressure)
  • Resolution: 0.1C
  • Display: 4-digit LED
  • Temp control accuracy: ±1.5°C (at 150°C)
  • Control type: microprocessor PID
  • No. of shelf positions: 3
  • No. of shelves: 3 (stainlees steel)
  • Power (VAC): 115
  • Power (Hz): 50/60

Posted in Vacuum Ovens | Tagged , , , , | Leave a comment

Vacuum Oven 2.3CU.FT; 120VAC

Vacuum Oven 2.3CU.FT; 120VAC

Vacuum Oven 2.3CU.FT; 120VAC Rating:
List Price: unavailable
Sale Price: $3,890.00
Availability: unspecified

Product Description

science-lab-ovens

Details

  • Lab Companion Vacuum Ovens
  • Feature wide temperature range for a variety of test applications
  • Ideal for separating solvents from a solution without high temperature drying
  • Heat-tempered full view window allows continuous monitoring of chamber
  • User-friendly control panel simplifies operation
  • Capacity (Liters): 51
  • Minimum temperature (° C): Ambient ±5
  • Minimum temperature (° F): 41
  • Maximum temperature (° C): 250
  • Maximum temperature (° F): 482
  • Capacity (cu ft): 2
  • Temp uniformity: ±1.5°C at 150°C
  • Manufacturer number: AAH13126U
  • Vacuum range: 0 - 0.1 MPa
  • Rise time: 100°C within 85 min
  • Vacuum display: Analog
  • Resolution: 1°C
  • Shpg wt (lbs): 227 (103 kg)
  • Display: Digital LED
  • Model: AAH13126U
  • Temp control accuracy: ±2.0°C
  • Control type: Digital PID with Auto Tuning and Calibration
  • No. of shelf positions: 3
  • No. of shelves: 3
  • Power (VAC): 120
  • Power (Hz): 50/60
  • Construction: Stainless steel interior
  • Overall dimensions: 31-3/4"W x 23-1/2"H x 22"D
  • Chamber size (" W): 15.75
  • Chamber size (" H): 15.75

Posted in Vacuum Ovens | Tagged , , , , | Leave a comment

Thermo Scientific Lindberg Blue M Vacuum Oven; 42.5L; 1 Door, 3 Shelves; 208/240V, 1250w

Thermo Scientific Lindberg Blue M Vacuum Oven; 42.5L; 1 Door, 3 Shelves; 208/240V, 1250w

Thermo Scientific Lindberg Blue M Vacuum Oven; 42.5L; 1 Door, 3 Shelves; 208/240V, 1250w Rating:
List Price: unavailable
Sale Price: $6,330.00
Availability: unspecified

Product Description

Oven, Vacuum; Thermo Scientific Lindberg/Blue M; 260C; Digital microprocessor control; Painted cabinet; 1 door; 3 shelves; Interior dimension: 12W x 18D x 12 in.H; 42.5L (1.5 cu. ft.); 208/240V; 1250w; w/Magnetic latches; 114kg (250 lb.)

Details

No features available.

Posted in Vacuum Ovens | Tagged , , , , | Leave a comment

Thermo Scientific Napco Vacuum Oven; Capacity: 0.45 cubic ft.; 230V 50/60Hz, 500w, 2.1A

Thermo Scientific Napco Vacuum Oven; Capacity: 0.45 cubic ft.; 230V 50/60Hz, 500w, 2.1A

Thermo Scientific Napco Vacuum Oven; Capacity: 0.45 cubic ft.; 230V 50/60Hz, 500w, 2.1A Rating:
List Price: unavailable
Sale Price: $2,440.00
Availability: unspecified

Product Description

Oven,Vaccum; Thermo Scientific; Electrical Requirements: 230V 50/60Hz, 2.1A, 500w; Capacity: 0.45 cu. ft. (0.013m3) capacity; Precision Scientific No.: 51220167

Details

No features available.

Posted in Vacuum Ovens | Tagged , , , , | Leave a comment

Yamato Large-Capacity DP Series Vacuum Drying Ovens; DP-63; Wt. Approx. 639 lb.

Yamato Large-Capacity DP Series Vacuum Drying Ovens; DP-63; Wt. Approx. 639 lb.

Yamato Large-Capacity DP Series Vacuum Drying Ovens; DP-63; Wt. Approx. 639 lb. Rating:
List Price: unavailable
Sale Price: $15,379.96
Availability: unspecified

Product Description

Oven, Vacuum Drying; Yamato ScientifiC; DP Series; Model ADP-21/31, DP-43/63, DP-63, Wt. Approx. 639 lb.

Details

No features available.

Posted in Vacuum Ovens | Tagged , , , , | Leave a comment

Fisher Scientific Isotemp Economy Vacuum Oven; Capacity: 45.3L; 120V 50/60Hz, 1700w, 14.2A

Fisher Scientific Isotemp Economy Vacuum Oven; Capacity: 45.3L; 120V 50/60Hz, 1700w, 14.2A

Fisher Scientific Isotemp Economy Vacuum Oven; Capacity: 45.3L; 120V 50/60Hz, 1700w, 14.2A Rating:
List Price: unavailable
Sale Price: $3,682.09
Availability: unspecified

Product Description

Oven, Economy Vacuum; Fisher Scientific Isotemp; 1.6 cu. ft.; 120V 50/60Hz, 1700w, 14.2A (Comes with domestic 20A plug; 20A service required); Vacuum: 0 to 30Hg; With two adjustable shelves

Details

No features available.

Posted in Vacuum Ovens | Tagged , , , , | Leave a comment
